3-way flanged valve, PN 16/10 (pn.)
BUE
How energy efficiency is improved
Efficient use in continuous control systems
Kenmerken
-
Continuous control of cold and hot water in closed circuits
-
Water quality as per VDI 2035
-
In combination with AVP 242 valve actuators as a control unit
-
Not suitable for drinking water
-
Valve with flange connection as per EN 1092-2, seal form B, for PN 16 and PN 10
-
Regulating valve, free of silicone grease, painted black
-
The control passage is closed when the spindle is moved out
-
Used as a control valve
-
Valve body and seat made of grey cast iron
-
Stainless-steel spindle
-
Plug made of brass with glass-fibre reinforced PTFE sealing ring
-
Stuffing box made of brass with wiper ring and double O-ring seal made of EPDM
Datasheets
Montage-instructies
Servicedocumentatie
Verklaring betreffende materialen en milieu
Brochures
BUE: Three-way flanged valves, PN 16/10
pdf : 2 MB
pdf
0372249 (VXN, BXN, VUD, BUD, VUE, BUE)
pdf : 283 KB
pdf
AVP243F . . ., AVP244F . . .
pdf : 5 MB
pdf
0378284 (VU . , BU . ,)
pdf : 499 KB
pdf
AVP242F001 (VU . , BU . )
pdf : 3 MB
pdf
VUD, BUD, VUE, BUE DN65...100(150)
pdf : 511 KB
pdf
AVP242F021
pdf : 4 MB
pdf
VUD, BUD, VUE, BUE
pdf : 2 MB
pdf
VUD, BUD, VUE, BUE, VQD, BQD, VQE, BQE
PDF : 227 KB
PDF
BUE015...150
PDF : 155 KB
PDF
